2 - 4 Circuits Optical Slipring , Single Mode Fiber Optic Rotary Joints

Products

Non Mercury Slip Ring

sales@3kmlink.com

+8618813988775

Contact Now

2 - 4 Circuits Optical Slipring , Single Mode Fiber Optic Rotary Joints

MOQ:	1
Price:	Negotiate
Standard Packaging:	Carton
Delivery Period:	2-6 Weeks, Stock Available
Payment Method:	T/T
Supply Capacity:	300 PCS/Week, Stock Available

Detail Information

Product Description

Detail Information

Place of Origin

Shenzhen , China

Brand Name

Hiscience

Certification

Model Number

HF02F-FC001

Name:

Optical Slipring

Fiber Type:

Single Mode(9/125 μm)

NO.of Circuits:

N≤4 According To Customer’s Request

Wavelength Range:

780-1650(Default:1310& 1550 Nm)

Insertion Loss:

≤ 4.0dB

Insertion Loss Variations:

≤±1.0dB

Highlight:

4 Circuits Optical Slipring

ISO Fiber Optic Rotary Joints

Single Mode Fiber Optic Rotary Joints

Product Description

Fiber Optic Slip Ring, 2 to 4 Circuits of Optical Signals

Product Description:

Features:

Low insertion loss

Optical transmssion technology of multi-channel, no
electroma gnetic leakage and anti-elertromagnetic interference

leakage and anti-electromagnetic interference

Contactless signal transimission

Inteorated FORI with electriral slip ring

Typical application:

Automotive Industry: Fiber optic slip rings find application in automotive systems, including electric vehicles and autonomous vehicles, for optical signal transmission in communication networks, sensing, and control systems.

Railway and Transportation: Fiber optic slip rings are utilized in railway systems, transportation equipment, and signaling systems to enable continuous optical signal transmission for communication, control, and signaling between rotating and stationary parts.

Marine and Offshore Systems: Fiber optic slip rings find application in marine and offshore systems, including shipboard equipment, offshore platforms, and underwater cables, for optical signal transmission in communication, monitoring, and control systems.

Options:

Number of optical Circuits

Wavelength Range

Housing Material

Fiber Pigtail Connector Type

Fiber Connector TypeST. LC

Installation Modes

Specifications:

Technical Specifications
Fiber Type	Single Mode(9/125 μm)
NO.of Circuits	N≤4 According to customer’s request
Wavelength Range	780-1650(Default:1310& 1550 nm)
Insertion Loss	≤ 4.0dB
Insertion Loss Variations	≤±1.0dB
Return Loss	≥45dB
Optical Crosstalk	≥70
Max. Optical Power	25dBm
Roating Speed	2000rmp
Working Life	≥50 million (300 rpm)
Pulling Strength	≥75N
Working Temperature	-40~75℃
Storage Temperature	-45~85℃
Weights	25g
Protection(IP Grade)	IP65
Housing Material	Stainless Steel
Connector Type	Default:FC/PC
Package Style	Pigtails on both ends, default.o3.0mm, 1.0 meters long
Vibration Standard	MIL-STD-167-1A
Mechanical Shock	MIL-STD-810G

Drawing for HF02F-FC001:

2 - 4 Circuits Optical Slipring , Single Mode Fiber Optic Rotary Joints 0

2 - 4 Circuits Optical Slipring , Single Mode Fiber Optic Rotary Joints 1

FAQ:

Can fiber optic slip rings be used in explosive environments?

Yes, there are fiber optic slip rings that are specifically designed for use in explosive environments, such as oil refineries or chemical plants. These slip rings are made with explosion-proof materials and meet safety standards.

Are fiber optic slip rings compatible with other communication protocols?

Yes, fiber optic slip rings can be compatible with various communication protocols such as Ethernet, USB, or RS-232. This allows for integration with different types of equipment and systems.

Can fiber optic slip rings transmit analog signals?

Yes, fiber optic slip rings can transmit analog signals such as audio or video signals. They can maintain the quality and integrity of analog signals during transmission.
