ISO High Speed 6 Circuit Slip Ring Manufacturers High Reliability Long Lifespan

MOQ:	1
Price:	Negotiate
Standard Packaging:	Carton
Delivery Period:	1-2 Weeks, Stock Available
Payment Method:	T/T
Supply Capacity:	10000 PCS/Week, Stock Available

Detail Information

Product Description

Detail Information

Place of Origin

Shenzhen , China

Brand Name

Hiscience

Certification

Model Number

3KM-MS124F0-0602（3KM06-05-03HW）

Name:

6 Circuit Slip Ring Manufacturers

Circuits &Current:

Voltage:

0-240 VAC/DC

Dielectric Strength:

≥500V@50Hz

Working Speed:

0~300RPM

Working Temperature:

-30'C~+70℃

Highlight:

ISO 6 Circuit Slip Ring

6 Circuit Slip Ring Manufacturers

High Speed Slip Rings Manufacturers

Product Description

Capsule Slip Rings 6 circuits 2A

Product Description:

Features:

Six circuits: The Capsule Slip Ring is equipped with six circuits, providing multiple pathways for signal and power transmission.

2A Rated Current: With a rated current of 2A per circuit, this slip ring can handle a significant amount of electrical current, allowing for reliable power transmission.

Efficient Signal Transmission: The slip ring is designed to maintain signal integrity, enabling the transmission of high-frequency or data-intensive signals without degradation.

Typical Application:

Amusement Rides: They are used in amusement park rides, such as Ferris wheels and carousels, to enable rotation while transmitting control signals and power.

Surveillance Systems: Capsule Slip Rings are employed in surveillance systems, enabling continuous rotation of PTZ cameras while transmitting video signals and power.

Renewable Energy Systems: Capsule Slip Rings are employed in various renewable energy systems, including solar trackers and tidal energy devices, to transmit power and control signals.

Specifications:

Electrical Parameter
Circuits &Current	6 / 2A
Lead Wire Size	AWG28# Lead Wire
Voltage	0-240 VAC/DC
Dielectric Strength	≥500V@50Hz

Insulation Resistance	100㏁@500VDC

Electrical Noise	≤10㏁

Mechanical Parameter
Lead Wire Size	Stator:250±10mm Rotor:250±10mm
Working Speed	0~300RPM
Contact Material	Gold-on-gold
Contact Material	Gold-on-gold
Housing Materia	Cap Sleeve Aluminum Alloy Oxidation
Housing Materia	Cap Sleeve Aluminum Alloy Oxidation
Working Temperature	-30'C~+70℃
Protection(IP Grade)	IP51
Working Humidity	≤85%RH
Reliability	High Reliability Long Lifespan

Drawing for 3KM-MS124F0-0602(3KM06-05-03HW):

ISO High Speed 6 Circuit Slip Ring Manufacturers High Reliability Long Lifespan 1

FAQ:

What are the safety features of capsule Slip Ring ?

Capsule Slip Ring can include safety features such as overcurrent protection and short-circuit prevention to ensure the protection of connected equipment and personnel.

Can capsule Slip Ring handle both AC and DC currents?

Yes,capsule Slip Ring can handle both AC and DC currents, making them suitable for a wide range of electricalapplications.

Are capsule Slip Rings suitable for high-speed rotating applications?

Capsule Slip Ring can be designed to accommodate high-speed rotating applications, with considerations for factors such as centrifugal forces, balance, and contact reliability at high speeds.
