Innovative Rotary Unions for High-Performance Industrial Machinery

MOQ:	1
Price:	Negotiate
Standard Packaging:	Carton
Delivery Period:	4-6 Weeks, Stock Available
Payment Method:	T/T
Supply Capacity:	2000 PCS/week, Stock Available

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Hiscience

Certification

Model Number

HST28-P10-S16-G02

Number Of Circuits:

10 Circuits 10 A+ 16 Signals+ 2 Shield

Working Temperature:

-40℃~+80℃

Operating Speed:

0-200rpm

Housing Material:

Aluminum Alloy

Contact Material:

Precious Metal

Electrical Noise:

≤10mΩ

Connection Thread Size:

M5, 4mm

Pressure:

1 Mpa

Product Description

Slip Rings 10 Circuits 10 A+ 16 Signals+ 2 Shield

Product Description:

Integrated Pneumatic-Electrical Design: Combines electrical circuits with a pneumatic passage in one unit, saving space and simplifying installation.

Precious Metal Contacts: Ensures reduced wear, high conductivity, and extended service life under continuous operation.

Durable Housing: Aluminum alloy construction provides strength, corrosion resistance, and a lightweight design.

Applications:

Textile Machinery: Provides power, signals, and compressed air for high-speed sewing and embroidery equipment, ensuring smooth fabric handling and precise control.

Packaging Equipment: Enables continuous rotation of sealing and labeling heads while transmitting signals and air pressure, improving efficiency in food and consumer goods packaging.

Mixers and Process Equipment: Maintains stable connections in mixers for food, chemical, and pharma industries, with low torque for smooth shaft rotation.

Specifications:

**Electrical Parameter**
Circuits/Current	10 Circuits 10 A+ 16 Signals+ 2 Shield
Voltage	0-380VAC/DC
Lead Wire size	AWG17#/AWG24# Teflon Insulated *RVSP-80.15mm² Cable**
Dielectric strength	≥500V@50HZ
Insulation Resistance	500MΩ@500VDC
Dynamic Contact Resistance	≤10mΩ

**Mechanical Parameter**
Working Speed	0-200RPM
Protection(lP Grade)	IP51
Working Temperature	-40℃~+80°C
Contact Material	Precious Metal
Housing Material	Aluminum Alloy

**Pneumatic Parameter**
Passages	1 Passage
Connection Thread Size	M5, 4mm
Pressure	1 Mpa
Transmitting Media	Compressed Air

Drawings:

FAQ:

Q: Can this slip ring transmit power, signals, and air at the same time?
A: Yes. It supports 10 × 10A power circuits, 16 signal circuits, plus 1 pneumatic passage, making it ideal for hybrid transmission.

Q: Will the signals suffer from interference?
A: No. The slip ring features shielded wiring and precious metal contacts, ensuring low noise and stable signal transmission.

Q: Is customization available?
A: Yes. We offer customized solutions for circuit number, current rating, signal type, pneumatic or hydraulic passages, and dimensions to meet specific requirements.
