2 Circuits Signal Slip Ring Pancake Compact Space Saving Design

Pancake Slip Rings 2 circuits signal

Product Description:

Features:

• 2 signal channels, capable of transmitting various signal types
• Ultra-thin design, space-saving
• High rotating speed, stable signal transmission
• Excellent performance, reliable and durable
• Customizable options to meet different needs
• Suitable for various industrial applications, widely used in medical, aerospace, automation, etc.

Typical Application:

• Robotics: Flat slip rings are widely used in robotic systems to transmit power, signals and data between stationary and rotating parts. They enable smooth, continuous rotation without cable twisting or tangles, ensuring efficient and reliable robot motion.

• Packaging Machinery: Flat slip rings are used in packaging machinery where they help transmit power and control signals to rotating parts such as turntables, drums and packaging heads. This makes synchronized operations possible and increases the productivity of the packaging process.

• Wind Turbine: Flat slip rings are an important component in wind turbines. They ensure the transmission of power and signals from the rotating blades to the stationary control system. This enables real-time monitoring, control and maintenance of wind turbines to maximize energy production.

Specifications:

Drawing for HP25-S02:

FAQ:

What is a pancake slip ring?

A pancake slip ring is a compact and flat rotary electrical connector that allows the transmission of power, signals, and data between stationary and rotating parts without the need for cables. It consists of a stationary part (stator) and a rotating part (rotor) with conductive rings and brushes that make electrical contact.

How does a pancake slip ring work?

Pancake slip rings work by utilizing conductive rings and brushes to establish electrical connections between the stationary and rotating parts. As the rotor rotates, the brushes maintain contact with the rings, allowing for the transmission of electrical signals and power across the interface.

What are the advantages of using pancake slip rings?

Compact Design: Pancake slip rings have a flat and space-saving design, making them ideal for applications with limited installation space.

Low Electrical Resistance: They offer low electrical resistance, ensuring efficient power transmission and minimizing signal loss.

Smooth Rotation: Pancake slip rings enable smooth and continuous rotation without cable twisting or tangling, ensuring reliable operation.

Wide Range of Signal Transmission: They can transmit a variety of signals, including power, analog and digital signals, Ethernet, USB, and more.

Customizability: Pancake slip rings can be customized to meet specific application requirements, including the number of rings, current capacity, signal types, and more.
